Horizontal Microscope - Single Head

The Single Head Horizontal Microscope is a robust and versatile digital microscope system engineered for precision inspection, repair work, and industrial testing environments. Designed with a horizontal stand structure for stable operation and comfortable workflow, this model is ideal for electronics servicing, PCB inspection, laboratory use, and manufacturing quality control. The system is equipped with a high-performance imported CMOS image sensor platform, offering clear, bright, and accurate image reproduction for observing micro-components, solder joints, connectors, and surface details. Using a 1/2.8-inch image sensor, the microscope provides a wider field of view compared with traditional 1/3-inch sensors, allowing users to inspect larger working areas while maintaining image clarity. Combined with a 2.9μm × 2.9μm pixel size, the camera delivers improved sensitivity and reduced noise for more stable image performance. High-Definition Output Options The H1602TW supports: HDMI output: 1080P at 60fps for smooth real-time display on external monitors USB output (MJPG): 1920 × 1080 / 30fps 1280 × 720 / 30fps 640 × 480 / 30fps 320 × 240 / 30fps This allows direct monitor viewing or PC integration depending on workflow needs. Optical Performance The microscope includes a 0.7X–4.5X optical zoom lens with 20X to 135X continuously adjustable magnification, giving users the flexibility to move from wide overview inspection to close-up detail analysis. An optional 10X–270X magnification configuration is also available. Stable Work Platform Designed for practical use, the system includes: Bottom plate size: 380mm × 260mm × 23mm Mobile loading platform: 200mm × 125mm This provides a large and stable workspace for circuit boards, mechanical parts, and small assemblies. Professional Features Include: Manual / automatic exposure modes One-click exposure control Adjustable exposure compensation Manual / automatic white balance One-click white balance Independent red, green, and blue adjustment 8 customizable line drawing functions Adjustable line color, thickness, and position Center crosshair display on/off TF card storage support up to 64GB Horizontal and vertical mirror modes Ideal Applications PCB inspection Electronics repair & soldering Mobile phone servicing Precision assembly Laboratory observation Industrial quality control Educational training Combines professional image quality, flexible connectivity, and a stable horizontal microscope platform, making it an excellent solution for demanding inspection tasks.
